35 × 7.5 mm Calha em Alumínio com Ranhuras DIN 4.2 × 12 mm
YOCL Electric 35 × 7.5 mm aluminium din rail with 4.2 × 12 mm slots for equipment requiring this mounting profile.
- Aluminium construction with a top-hat section.
- 35 mm profile width and 7.5 mm depth.
- Nominal thickness choices: 0.7 / 0.9 / 1.1 mm.
- Elongated 4.2 × 12 mm fixing slots.
- Standard length choices: 1 m / 2 m.
- Select by the device mounting profile, required thickness and fixing arrangement.
Visão Geral
The 35 × 7.5 mm aluminium DIN rail with 4.2 × 12 mm slots from YOCL Electric provides a top-hat mounting section for electrical assemblies requiring an aluminium rail. The profile is 35 mm wide and 7.5 mm deep.
The series has 3 nominal thickness choices: 0.7 / 0.9 / 1.1 mm. It uses elongated 4.2 × 12 mm mounting slots. Standard lengths are 1 m / 2 m. Each enquiry should identify the required thickness and rail length together with the mounting profile.
Características
- Aluminium construction with a top-hat section.
- 35 mm profile width and 7.5 mm depth.
- Nominal thickness choices: 0.7 / 0.9 / 1.1 mm.
- Elongated 4.2 × 12 mm fixing slots.
- Standard length choices: 1 m / 2 m.
Especificações Técnicas
| Parâmetro | Especificação |
|---|---|
| Marca | YOCL Elétrico |
| Material | Alumínio |
| Perfil | Top-hat |
| Profile width | 35 mm |
| Profile depth | 7.5 mm |
| Nominal thickness options | 0.7 / 0.9 / 1.1 mm |
| Base configuration | Slotted |
| Slot shape | Elongated |
| Slot width × length | 4.2 × 12 mm |
| Standard length | 1 m / 2 m |
Dimensão
| Dimensão | Valor |
|---|---|
| Profile width × depth | 35 × 7.5 mm |
| Nominal thickness options | 0.7 / 0.9 / 1.1 mm |
| Slot width × length | 4.2 × 12 mm |
| Standard length | 1 m / 2 m |
Guia de Seleção
Match the 35 × 7.5 mm top-hat profile to the intended device mounting requirement. Keep the aluminium material, chosen thickness and 4.2 × 12 mm slot size in the purchase description so this configuration is identified precisely when comparing rail specifications.
Review the 4.2 × 12 mm slot opening against the intended fixing arrangement. The slot size describes each opening; any required hole spacing should be checked against the panel drawing. Include the fixing pattern where it forms part of the purchase requirements.
Choose the standard rail length using the planned rail runs and project quantity. Keep the selected length and thickness explicit when comparing quotations or preparing the purchase order.
Informações de Encomenda
For an enquiry, state the 35 × 7.5 mm Aluminium DIN Rail with 4.2 × 12 mm Slots, selected thickness, standard length and quantity. Include the device mounting requirement and any relevant panel drawing. Provide any project-specific material or surface-finish requirements.
