Visão Geral
The YOCL ELECTRIC 35 × 7.5 mm slotted steel DIN rail is a TS35 top hat rail for electrical panels and enclosures using devices specified for this mounting profile. Its 35 mm mounting width and 7.5 mm profile depth define the section to check against the equipment requirement.
Choose from standard slots, long slots, blue-white appearance, a conventional 1.0 mm section or a ribbed section. Each configuration has its own nominal thickness, mounting slot dimensions and standard lengths, shown together in the table below.
Características
- 35 × 7.5 mm top hat profile: a defined mounting section for equipment requiring this rail geometry.
- Steel construction: nominal thickness choices are tied to the selected configuration.
- Three elongated slot patterns: 6.2 × 15 mm, 5.2 × 25 mm or 5.2 × 15 mm.
- Profile and appearance choices: a blue-white appearance option and a ribbed section are included in the series.
- Paired length selections: standard lengths follow the configuration table.
Especificações Técnicas
Dimensão
The rail section is 35 mm wide and 7.5 mm deep. Slot sizes describe the width and length of each elongated opening. Select the slot dimensions and rail length from the same configuration row when specifying the panel fixing arrangement.
Guia de Seleção
Start with the device manufacturer’s required rail profile. Check both the 35 mm width and 7.5 mm depth, then select a configuration with the appropriate nominal thickness and slot pattern.
For a 0.5 m standard length, use the standard-slot or long-slot row. The blue-white, conventional 1.0 mm and ribbed configurations list 1 m and 2 m lengths. Keep the configuration, thickness, slots and length together in the purchase specification.
Use the blue-white designation as an appearance choice. For the ribbed section, specify its 0.8 mm nominal thickness and 5.2 × 15 mm slots. Where fixing positions are critical, provide the panel mounting drawing with the enquiry.
Informações de Encomenda
Specify YOCL ELECTRIC 35 × 7.5 mm slotted steel DIN rail, configuration name, nominal thickness, slot size, standard length and quantity. Include the device mounting reference and any required fixing-hole layout so the quotation addresses the complete mechanical specification.
