HSS PEEK Cable Ties
Outside-serrated PEEK cable ties with a smooth bundle-contact surface for high-temperature applications.
- 3 listed configurations.
- Material: PEEK.
- Model-specific specifications shown in the table.
Overview
Outside-serrated PEEK cable ties with a smooth bundle-contact surface for high-temperature applications.
Features
- Material: PEEK.
- 3 listed configurations for selection.
Technical Specifications
| Parameter | Specification |
|---|---|
| Material | PEEK |
| Configurations | 3 |
| Operating temperature | −55 to +240 °C |
Dimension
Dimensions are in millimetres. Force values are in the units stated in each column and do not establish working-load ratings.
| Model | Length (mm) | Width (mm) | Max. bundle diameter (mm) | Thickness (mm) | Tensile strength (N) | Colour |
|---|---|---|---|---|---|---|
| HSS-34145PEEK | 145 | 3.4 | 35 | 4 | 230 | Beige |
| HSS-47250PEEK | 250 | 4.7 | 65 | 4 | 300 | Beige |
| HSS-47220PEEK | 220 | 4.7 | 56 | 8 | 380 | Beige |
Selection Guide
Check the listed dimensions and configuration against the intended application. Material compatibility and exposure conditions must suit the installation.
Ordering Information
Provide the complete model or specification and quantity when requesting a quotation.
