VO-TR Through-Type Waterproof Brass Cable Glands

VO-TR through-type waterproof brass cable glands are available with Metric or PG threads. The source specifies a nickel-plated brass body, PA clamping parts and NBR sealing components.

Metric models from M12×1.5 to M100×2
PG models from PG7 to PG63
IP68 at 10 bar with O-ring, as stated in the source catalogue
Model-specific mounting-hole diameter, GL thread length and spanner size

Inquire about this product

Overview

VO-TR through-type waterproof brass cable glands are cable-entry fittings with Metric and PG thread options. The source specifies nickel-plated brass main parts, a PA nylon clamping component, and NBR rubber sealing parts and O-ring. The through-type construction lets the cable pass through the gland while its clamping assembly secures the cable at the enclosure entry.

The catalogue states IP68 protection at 10 bar when the O-ring is used. The supplied model tables list cable outside-diameter ranges and mounting dimensions for each code. This page covers only the Metric and PG models shown in the supplied material.

Features

Two thread systems: Choose Metric or PG according to the enclosure entry.
Through-type assembly: The cable passes through the gland body and clamping components.
Nickel-plated brass parts: The catalogue identifies the metal main parts as nickel-plated brass.
PA and NBR components: PA nylon clamping parts and NBR rubber sealing parts are specified.
Multiple clamping ranges: Models of similar thread size can cover different cable diameters.
Installation dimensions listed: Thread outside diameter, mounting-hole range, GL thread length and spanner size are provided by model.

Technical Specifications

Parameter	Specification
Series	VO-TR
Product type	Through-type waterproof brass cable gland
Listed thread types	Metric and PG
Main metal parts	Nickel-plated brass
Clamping component	PA nylon
Seal and O-ring	NBR rubber
Protection degree	IP68 at 10 bar with O-ring (source catalogue statement)
Static operating temperature	−40 to +100 °C; short exposure to +120 °C
Dynamic operating temperature	−20 to +80 °C; short exposure to +100 °C
Metric sizes	M12×1.5 through M100×2; see individual rows
PG sizes	PG7 through PG63; see individual rows
Cable outside diameter	Model dependent; see tables
Thread length GL	Model dependent; see tables

Dimension

Cable ranges below are shown as minimum–maximum cable outside diameter in mm. The source catalogue often prints the upper value first. Thread outside diameter, mounting-hole range, GL and joint length H are also in mm. A dash indicates a dimension that was not supplied for that thread group.

Metric thread models

Catalogue code	Thread	Cable Ø (mm)	Thread O.D. (mm)	Mounting hole (mm)	GL (mm)	H (mm)	Spanner (mm)
VO-M12-TR	M12×1.5	3–6.5	12	12–12.2	7	19	14
VO-M14-TR	M14×1.5	4–8	14	14–14.2	7	19	17
VO-M16-TR	M16×1.5	4–8	16	16–16.2	8	20	18
VO-M18-TR	M18×1.5	5–10	18	18–18.2	8	21	20
VO-M20-TR	M20×1.5	6–12	20	20–20.2	8	22	22
VO-M22-TR	M22×1.5	10–14	22	22–22.2	8	23	24
VO-M24-TR	M24×1.5	10–14	24	24–24.2	9	25	24/27
VO-M25A-TR	M25×1.5	10–14	25	25–25.2	9	25	24/27
VO-M25B-TR	M25×1.5	8–16	25	25–25.2	9	27	27
VO-M25C-TR	M25×1.5	13–18	25	25–25.2	9	27	30/27
VO-M27A-TR	M27×1.5	13–18	27	27–27.2	9	27	30
VO-M27B-TR	M27×2	13–18	27	27–27.2	9	27	30
VO-M28A-TR	M28×1.5	13–18	28	28–28.2	9	27	30
VO-M28B-TR	M28×2	13–18	28	28–28.2	9	27	30
VO-M30A-TR	M30×1.5	13–18	30	30–30.2	9	29	30/32
VO-M30B-TR	M30×2	13–18	30	30–30.2	9	29	30/32
VO-M32A-TR	M32×1.5	15–22	32	32–32.2	10	29	35
VO-M32B-TR	M32×1.5	16–20	32	32–32.2	10	29	35
VO-M32C-TR	M32×2	15–22	32	32–32.2	10	29	35
VO-M36A-TR	M36×1.5	18–25	36	36–36.2	10	31	40
VO-M36B-TR	M36×2	18–25	36	36–36.2	10	31	40
VO-M37A-TR	M37×1.5	18–25	37	37–37.2	10	31	40
VO-M37B-TR	M37×2	18–25	37	37–37.2	10	31	40
VO-M40A-TR	M40×1.5	18–25	40	40–40.2	11	31	40/45
VO-M40B-TR	M40×2	18–25	40	40–40.2	11	31	40/45
VO-M40C-TR	M40×1.5	22–30	40	40–40.2	11	35	45
VO-M40D-TR	M40×2	22–30	40	40–40.2	11	35	45
VO-M42A-TR	M42×1.5	22–30	42	42–42.2	11	35	45
VO-M42B-TR	M42×2	22–30	42	42–42.2	11	35	45
VO-M60A-TR	M60×1.5	37–44	60	60–60.2	13	38	64
VO-M60B-TR	M60×2	37–44	60	60–60.2	13	38	64
VO-M63A-TR	M63×1.5	37–44	63	63–63.2	13	38	64/68
VO-M63B-TR	M63×2	37–44	63	63–63.2	13	38	64/68
VO-M64A-TR	M64×1.5	37–44	64	64–64.2	13	38	64/68
VO-M64B-TR	M64×2	37–44	64	64–64.2	13	38	64/68
VO-M72-TR	M72×2	42–52	72	72–72.2	15	42	78
VO-M75-TR	M75×2	42–52	75	75–75.2	15	42	78
VO-M80-TR	M80×2	50–62	80	80–80.2	15	45	86/88
VO-M88-TR	M88×2	60–70	88	88–88.2	15	45	98
VO-M100-TR	M100×2	70–80	100	100–100.2	15	45	110

PG thread models

Catalogue code	Thread	Cable Ø (mm)	Thread O.D. (mm)	Mounting hole (mm)	GL (mm)	H (mm)	Spanner (mm)
VO-PG7-TR	PG7	3–6.5	12.5	12.5–12.7	7	—	14
VO-PG9-TR	PG9	4–8	15.2	15.2–15.4	8	—	17
VO-PG11-TR	PG11	5–10	18.6	18.6–18.8	8	—	20/21
VO-PG13.5-TR	PG13.5	6–12	20.4	20.4–20.6	8	—	22
VO-PG16-TR	PG16	10–14	22.5	22.5–22.7	9	—	24
VO-PG21-TR	PG21	13–18	28.3	28.3–28.5	9	—	30
VO-PG25-TR	PG25	15–22	32	32–32.2	10	—	35
VO-PG29-TR	PG29	18–25	37	37–37.2	11	—	40
VO-PG36-TR	PG36	25–33	47	47–47.2	12	—	50
VO-PG42-TR	PG42	32–38	54	54–54.2	13	—	57
VO-PG48-TR	PG48	37–44	59.3	59.3–59.5	14	—	64
VO-PG63-TR	PG63	42–52	72	72–72.2	15	—	78

Selection Guide

First match the enclosure’s thread system and size. Then select the catalogue code whose cable outside-diameter range covers the actual cable. Verify mounting-hole diameter, GL, available enclosure clearance and spanner size. Include the full code and required quantity in the inquiry.

Dimension

VO-TR Through-Type Waterproof Brass Cable Glands dimension drawing
